- Small dimensions.
- High limiting and breaking capacity.
- Low power losses.
- The fuse-links do not contain harmful substances according to the RoHS Regulation (cadmium, lead and other).
- Utilization category aM for protection of motors, overcurrent relays, contactors and similar devices only against short-circuit.
- Nominale spanning : 400 ÷ 690 V a.c.
- Onderbrekingsvermogen : 120 kA
- Normen : IEC 60 269
Cylindrische zekering 22x58mm 690Vac 80A aM
Artikelnr:
PV2280AaM
€ 2,55
excl. BTW
(
€ 3,09
Incl. BTW
)
excl. BTW
(
Incl. BTW
)
(
Incl. BTW
)
Wil je een offerte ontvangen voor dit product?
Neem contact op. Wij bieden de beste prijsgarantie!
Omschrijving
Specificaties
Artikelnummer
- PV2280AaM
EAN
- 5415184508887
Model
- Ceramic fuse
Maat
- 22x58 mm
Voltage type
- AC/DC
Utilization category
- aM (switchgear protection)
Type of fuse status indicator
- Other
Rated voltage DC
- 250
Breaking capacity at nominal voltage, AC
- 120
Breaking capacity at nominal voltage, DC
- 120
Rated voltage AC
- 500
Rated current
- 80
Power loss at rated current
- 5,28
